- Inflate or deflate your tires automatically up to 145 psi.
- Wall-mounted unit with 25’ air hose to easily reach all tires on the vehicle.
- Only 2 min. 20 sec. to inflate a 11R22.5 tire from 0 to 100 psi.
- Loud audible signal warns you that the tire has reached the desired pressure.
- 4 measurement units (psi, bar, kPa, kg/cm2), overpressure system (OPS), LCD screen & backlight.
The Flatematic Single is a single outlet automatic tire inflator that will automatically start inflation or deflation once it is connected to the tire valve to precisely reach the selected pressure. Its clip-on chuck makes tire inflation more productive by allowing you to work away from the tire.
*Air compressor required.
Important: compressed air contains water and oil, use proper air filter between the source and device. Failure to do so will void the warranty.
| Specifications |
| Included |
- 25’ air hose with 1/4" NPT open chuck
- Quick coupling 1/4'' industrial
- Air hose support hook
- M6x38 screws (5x)
- User manual
|
| Features |
Fixed, Wall-mounted, Over pressure setting (OPS), Nitrogen compatible (n2) |
| Materials |
Aluminium |
| Color |
Black and blue |
| Air compressor required |
Yes |
| Air pressure - max. outlet (psi) |
145 |
| Air pressure - max. inlet (psi) |
150 |
| Reading accuracy (psi) |
0.29 |
| Airflow - max. (l/min) |
2600 |
| Airflow - max. (CFM) |
92 |
| Hose quantity |
1 |
| Hose length (inches) |
300 |
| Hose length (cm) |
760 |
| Chuck type |
Open |
| Certifications |
CE |
| Calibration certified |
Yes |
| Autocalibration |
Yes, on every unit start |
| Maintenance & calibration service |
Yes |
| Degree of protection |
IP66 |
| Supply voltage |
110 |
| Product dimensions - LxWxH (inches) |
9 x 10 1/2 x 3 1/2 |
| Product dimensions - LxWxH (cm) |
20 x 27 x 9 |
| Net weight (kg) |
6 |
| Net weight (lb) |
14 |
| Package dimensions - LxWxH (inches) |
12 x 12 x 9 |
| Package dimensions - LxWxH (cm) |
31 x 31 x 23 |
| Gross weight (kg) |
7 |
| Gross weight (lb) |
15 |
| Warranty |
1 year warranty |
